Radial piston pumps BRK501/502

BIERI radial piston pumps BRK are very robust radial piston pumps with high volumetric efficiency, wide speed range and high reliability, even under rough conditions.

Max. operating pressure 500 bar
Displacement volume 0.76 to 8,14 cm³/rev
Max. rotation speed 2000 rpm

Downloads

[Translate to EN:] Radialkolbenpumpen BRK 501/502
Features Advantages
Robust radial piston pump, valve controlled Preeminent power spectrum, broad range, multiport pumps, different media
Low piston clearance High volumetric efficiency on a wide speed range
Bearings are designed for maximum constant pressure (500 bar) Long operating lifetime
Self-venting Low noise level
Minimized dead volume of pistons, linked together with optimized design of suction valves Low pulsation
Combination with gear pump possible (see separate data sheet BKP) Enables supply of standard pumps as well as special customized models

Applications

  • Machine tools
  • Clamping device
  • Power units (e.g. for presses)
  • Lifting systems
  • Hydraulic tools
  • For applications in test benches use BRK701/702 or BRK11/1002

Design

  • Radial piston pump of modular design
  • With valve controlled pump elements
  • With 3, 5, 7 or 9 pumping elements

Technical Data

Hydraulic fluid mineral oil according to DIN 51524 (other fluids on request)
Fluid temperature range -20 to 80°C
Ambient temperature range -30 to 50°C
Viscosity range 5 to 220 mm²/s
Max. operating pressure 500 bar, peak pressure 700 bar (reduces bearing life)
Displacement volume 0.76 bis 6,33 cm³/rev
Operation pressure at suction port -0.2 bar to 0.5 bar gauge pressure
Filtration (recommendation) according to NAS 1638 class 6 resp. ISO/DIN 4406 17/15/12
Axial force onto driving shaft can’t be taken up
Radial force onto driving shaft on request
Max. rotation speed 2000 rpm
Direction of rotation any
Suction height Max. 500 mm
Weight see technical data sheet
Materiasl pressure flange: forged steel
driving shaft head: steel
cover: diecast aluminium
