Check valves RVH

Valves of type RVH are spring-loaded seat valves. The check valve is used for blocking of the flow in one and low-loss flow in the other direction. The closing element is guided.

Max. operating pressure 700 bar
Max. flow rate 25 l/Min

Downloads

[Translate to EN:] Rückschlagventil Typ RVM/RVH
Features/Design
Seated valve
As cardridge
Available with blocked or free flow in cardridge direction
With screw-in thread G1/8 and G1/4

Applications

  • Hydraulic systems
  • Clamping functions
  • Mobile hydraulics

Technical data

Hydraulic fluid mineral oil according to DIN 51524 part 1 and 2 (other fluids on request)
Fluid temperature range -20 to 120 °C
Ambient temperature range -30 to 120 °C
Viscosity range 2.8 to 800 mm²/s
Max. flowrate 25 l/min
Max. operating pressure 700 bar
Max. pressure drop see technical data sheet
Filtration (recommendation) according to NAS 1638 class 10 resp. ISO/DIN 4406 21/19/16
Material valve body: free-cutting steel (hardened)
closing element: bearing steel
valve seat: free-cutting steel (hardened)
